Sx4 issues

Kbreks

Well-Known Member
Has anyone ever experienced a Winchester sx4 trigger not working all the time. Ill pull up and pull the trigger, acts as if the safety is still on. I pull harder and it fires. Next few rounds fire just fine. Doesnt matter what shot im using and doesnt always happen. Winchester is 4-6 week turn around if i send it in and thats not an option. Hoping to sort it myself.

Sounds like a simple fix but i have no direct answer or solution. I would just knock the trigger assembly out and see what is dragging or lodged in there. Should be just a couple pins holding the assembly in place. If its a common problem YouTube should have an answer and solution.

Sounds like a simple fix but i have no direct answer or solution. I would just knock the trigger assembly out and see what is dragging or lodged in there. Should be just a couple pins holding the assembly in place. If its a common problem YouTube should have an answer and solution.
I tore it apart again. Seems as if the trigger geta held up between shells. Tossed it in the ultrasonic cleaner. Seems to have maybe fixed the issue. Wont know until I'm out again.

Very common problem with the SX4, sounds to me safety has crap in it.
Remove the trigger assembly, remove the detent spring and detent, remove safety button.
Clean, inspect and reassemble....may get it done. Make certain that the detent is oriented properly, they can be reversed from correct IIRC.
The safety is ambidextrous, should be some video on YT showing how to switch it IE disassembly and assembly. I think some Brownings use the identical setup.

Very common problem with the SX4, sounds to me safety has crap in it.
Remove the trigger assembly, remove the detent spring and detent, remove safety button.
Clean, inspect and reassemble....may get it done. Make certain that the detent is oriented properly, they can be reversed from correct IIRC.
The safety is ambidextrous, should be some video on YT showing how to switch it IE disassembly and assembly. I think some Brownings use the identical setup.
I Would also call winchester and explain the issue, they know the fix

I contacted Winchester and best they could offer was send it out.
Sounds like there might be something on the safety that's is loose, interfering with the trigger. when you have it apart for cleaning, see if the safety is solid or a bit sloppy, seems like it may shift/slide in front of trigger, I've read some posts on other forums, seems like it's a common thing with SX4. I'm not an expert, but your details make me want to check that safety.
Here's a "Hail Mary" attempt as assistance. :) Be sure that the hammer is cocked and the safety in the "ON" position when inserting the trigger assembly into the receiver. Then, once the trigger assembly is fully assembled into the receiver with all pins in place, push the bolt release button and see if the bolt slams shut on the empty chamber as it should.

Then, push the safety to the OFF position and then pull the trigger to drop the hammer on an empty chamber. Then pull the bolt handle fully to the rear to lock the bolt in the rearward position. If everything works as it should up to this point, then I think you've got it assembled correctly.
If my suggestion above doesn't solve the problem, then the problem is probably in the safety switch itself. I believe that gun has a trigger block safety located in the trigger assembly.

There might be metal shavings or other obstructions inside the trigger assembly of the new gun. In that case, flood the safety switch with almost any kind of liquid cleaner or lubricant (mineral spirits, kerosene, gun oil, or whatever) in an attempt to flush out and/or lubricate the safety. Work the safety back and forth repeatedly while it's well lubricated. That may flush out the safety switch and free up the operation of the trigger.

If all that fails , Gunsmith is an option, the more i read up on these shotguns, Some users have had that gun fire by itself , with no birds in sight.
get it checked!

Sounds like there might be something on the safety that's is loose, interfering with the trigger. when you have it apart for cleaning, see if the safety is solid or a bit sloppy, seems like it may shift/slide in front of trigger, I've read some posts on other forums, seems like it's a common thing with SX4. I'm not an expert, but your details make me want to check that safety.
Here's a "Hail Mary" attempt as assistance. :) Be sure that the hammer is cocked and the safety in the "ON" position when inserting the trigger assembly into the receiver. Then, once the trigger assembly is fully assembled into the receiver with all pins in place, push the bolt release button and see if the bolt slams shut on the empty chamber as it should.

Then, push the safety to the OFF position and then pull the trigger to drop the hammer on an empty chamber. Then pull the bolt handle fully to the rear to lock the bolt in the rearward position. If everything works as it should up to this point, then I think you've got it assembled correctly.
If my suggestion above doesn't solve the problem, then the problem is probably in the safety switch itself. I believe that gun has a trigger block safety located in the trigger assembly.

There might be metal shavings or other obstructions inside the trigger assembly of the new gun. In that case, flood the safety switch with almost any kind of liquid cleaner or lubricant (mineral spirits, kerosene, gun oil, or whatever) in an attempt to flush out and/or lubricate the safety. Work the safety back and forth repeatedly while it's well lubricated. That may flush out the safety switch and free up the operation of the trigger.

If all that fails , Gunsmith is an option, the more i read up on these shotguns, Some users have had that gun fire by itself , with no birds in sight.
get it checked!
I originally thought it was something to do with the safety but doing some tinkering the safety seems to work as it should. Everything is assembled as it should be now. Just have to get out and test it. Fingers crossed that it's good to go.
